When a given close is selected the display shows:
The value of the selected energy close.
The difference, in %, between the most recent energy close with respect of the
previous close.
A green arrow indicates a lower consumption than the previous close and a
red arrow indicates a higher consumption.
5.3.- ALARM MENU
The screen in Figure 89 is the alarm display menu screen. Where all the alarms programmed
in the unit and in the connected expansion modules are displayed, indicating a brief description
and the date and time of the alarm activation.
Figure 89: Main screen of alarm menu.
The alarm selected is indicated in white.
The display options appear in the lower area:
Previous, moves up the list of alarms.
Next, moves down the list of alarms.
.Disabled latch, displayed when the alarm selected does not have the latch option
enabled.
Unlock alarm, if the latch option has been programmed in an alarm and it has been
activated, the alarm will be unlocked with this option.
Main menu, back to the main menu, Figure 25.
105
Instruction Manual
CVM-B100 - CVM-B150
