● For all parameters:
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
Integration time:
Maximum value: 60 minutes.
Minimum value: 1 minute.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
5.6.11.- ENERGY CONSUMPTION COSTS.
The energy consumption costs are selected on this screen Figure 125:
 The cost per kWh of electricity of tariff 1 consumption.
 The cost per kWh of electricity of tariff 2 consumption.
 The cost per kWh of electricity of tariff 3 consumption.
 The currency.
Figure 125: Energy consumption costs conguration screen.
138
CVM-B100 - CVM-B150
Instruction Manual
