6.3.8.6. Energy closes
The Energy variables occupy 90 registers.
All other variables occupy 1 register each.
Energy closes
Variable
(1)
Address
1 day active energy close 2BC0 - 2C19
1 day reactive energy close total 2C24 - 2C7D
Index of the sample from the close of the day
(2)
2C7E
1 week active energy close 2C88 - 2CE1
1 week reactive energy close total 2CEC - 2D45
Index of the sample from the close of the week
(2)
2D46
1 month active energy close 2D50-2DA9
1 month reactive energy close total 2DB4 - 2E0D
Index of the sample from the close of the month
(2)
2E0E
Active energy at 1 year close 2E18 - 2E71
Total reactive energy at 1 year close 2E7C - 2ED5
Index of the sample of the following year close
(2)
2ED6
(1)
For these variables the Function 0x04 is implemented: reading registers.
(2)
The information in the index of the sample of the following year close is provided in order to know in what position
the registers are currently at, bearing in mind that this position is still empty and will be the next to be filled in when
the next close is made.
The registers have information on the energy at the moment of the close.
The close is calculated as the difference between the most recent energy value and the energy
logged in the previous period.
Note: The 90 registers must be read at once (as a group), otherwise it will respond with an
error.
6.3.9.- DELETING PARAMETERS
These parameters occupy 1 register each.
Parameters can be deleted using Function 0x05: writing a relay.
Table 65:Modbus memory map: Deleting parameters
Deleting parameters Address Value to be sent
System reset 07D0 0x00FF
Deleting energies 0834 0x00FF
Deleting maximum and minimum values 0837 0x00FF
Deleting of partial meter of tariff 1 energy consumed 0838 0x00FF
Deleting of partial meter of tariff 2 energy consumed 0839 0x00FF
Deleting of partial meter of tariff 3 energy consumed 083A 0x00FF
Deleting of partial meter of tariff 1 energy generated 083B 0x00FF
Deleting of partial meter of tariff 2 energy generated 083C 0x00FF
Deleting of partial meter of tariff 3 energy generated 083D 0x00FF
Initialises Maximum Demand 083E 0x00FF
Deleting of Maximum Demand maximum and minimum values 083F 0x00FF
204
CVM-B100 - CVM-B150
Instruction Manual
