10.7.- MBUS COMMUNICATIONS
General features
Maximum power of the module 2 W
Communications
Bus Wired M-Bus
Protocol Slave M-Bus compatible to EN 13757-2 and EN 13757-3
Baud rate 1200 - 2400 - 4800 - 9600
Primary address 1 ... 250
Stop bits 1
Parity even
Environmental features
Operating temperature -10ºC ... +50ºC
Storage temperature -20ºC ... +80ºC
Relative humidity (without condensation) 5 ... 95%
Maximum altitude 2000 m
Protection degree
(1)
IP30
Mechanical features
Dimensions (mm) Figure 225 and Figure 226
Weight 80 g
Enclosure V0 self-extinguishing plastic
Assembly Panel
(1)
This pollution degree hasn’t been tested by UL.
Standards
Safety requirements for electrical equipment for measurement, control
and laboratory use
IEC 61010: 2010
Electromagnetic compatibility (CEM). Part 6-2: Generic standards. Immu-
nity for industrial environments.
UNE-EN 6100-6-2:2006
Electromagnetic compatibility (CEM). Part 6-4: Generic standards. Emis-
sions standard for industrial environments.
UNE-EN 6100-6-4:2007
Coordination of the insulation of units installed in low voltage systems
(networks)
IEC 664: 2007
Information technology equipment. Radio disturbance characteristics.
Limits and methods of measurement.
UNE-EN 55022
Communication systems for and remote reading of meters - Part 2: Physi-
cal and link layer
UNE-EN 13757-2:2004
Communication systems for and remote reading of meters - Part 3: Dedi-
cated application layer
UNE-EN 13757-3:2004
Heat Meters - Part 3: Data exchange and interfaces UNE-EN 1434-3:2008
Safety requirements for electrical equipment for measurement, control,
and laboratory use - Part 1: General requirements
UL/CSA 61010-1 3rd edition
323
Instruction Manual
CVM-B100 - CVM-B150
