9.- TECHNICAL FEATURES
AC power supply ( CVM-B100-ITF, CVM-B150-ITF )
Rated voltage 100 ... 240 V ~
Frequency 50 ... 60Hz
Consumption
CVM-B100 CVM-B150
max. 23.9 VA max. 29.4 VA
Installation category CAT III 300 V
DC Power supply
Rated voltage
CVM-Bxxx-ITF-SDC CVM-Bxxx-ITF
20 ...120 V
120 ...300 V
Consumption
CVM-B100 CVM-B150 CVM-B100 CVM-B150
max.10.6 W max.13.8 W max.12.2 W max.11.9 W
Installation category CAT III 300 V
Voltage measurement circuit
Voltage measurement margin 20 ... 600 V ~
Frequency measurement margin 40 ... 70 Hz
Input impedance 1.2 MΩ
Minimum measurement voltage (Vstart) 10 V ~
Maximum voltage input consumption 0.15VA
Installation category CAT III 600 V
Current measurement circuit
Nominal current (In) .../5A , .../1A or .../0.250 A
Phase current measurement margin
In: .../5A In: .../1A In: .../0.250A
0.01...10A 0.01...2A 0.01 ...0.5A
Neutral current measurement margin
.../5A .../1A .../A (calculated)
0.02 ...10A 0.02...2A
0.02 ... 10A ( In: .../5A)
0.02 ... 2A ( In: .../1A)
0.02 ... 0.5A ( In: .../0.250A)
Maximum current, impulse < 1s 100 A
Minimum measurement current (Istart) 0.01 A 0.01 A 0.01 A
Maximum current input
consumption
0.9 VA
Installation category CAT III 600 V
Accuracy of measurements (in accordance with the IEC 61557-12 standard for PMD SD/SS)
.../5A .../1A .../0.250A
Voltage measurement
Class 0.2 ± 1 digit
(20 ...600 V~)
Class 0.2 ± 1 digit
(20 ...600 V~)
Class 0.2 ± 1 digit
(20 ...600 V~)
Neutral voltage measurement
Class 0.5 ± 1 digit
(50 ...600 V~)
Class 0.5 ± 1 digit
(50 ...600 V~)
Class 0.5 ± 1 digit
(50 ...600 V~)
Phase current measurement
Class 0.2 ± 1 digit
(0.05 ...8A)
Class 0.2 ± 1 digit
(0.01 ...1.2 A)
Class 0.2 ± 1 digit
(0.01 ...0.3 A)
Neutral current measurement
Class 1 ± 1 digit
(0.05 ...6A)
Class 1 ± 1 digit
(0.05 ...1.2 A)
Class 1 ± 1 digit
(Calculated)
Measurement of active and apparent
power (Vn 230/110 V~)
Class 0.5 ± 1 digit
(0.05 ...6 A)
Class 0.5 ± 1 digit
(0.01 ...1.2 A)
Class 0.5 ± 1 digit
(0.01 ...0.3 A)
Reactive power measurement
(Vn 230/110 V~)
Class 1 ± 1 digit
(0.05 ...6 A)
Class 1 ± 1 digit
(0.01 ...1.2 A)
Class 1 ± 1 digit
(0.01 ...0.3 A)
313
Instruction Manual
CVM-B100 - CVM-B150
