Calculated current, to select a software-based calculation by the unit of the neutral
current.
● For all parameters:
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the value programmed on the screen.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
Primary current:
For /5A and /1A secondary current: Maximum value: 10000.
For MC type secondary current: Maximum value: 1500.
Minimum value: 1.
Primary neutral current:
Maximum value: 10000.
Minimum value: 1.
The primary voltage x primary current value must be less than 60MW.
