Table 55 ( Continuation) : Configuration of custom screens: Variables.
Variables parameter
Variable Value Variable Value
Apparent Power 0x000A
CO
2
Emissions
0x0018
Power Factor 0x000B
Cost
0x0019
Cosine
φ
0x000C Empty (no parameters) 0x001A
Voltage THD 0x000D
Table 56: Conguration of custom screens: Phases.
Phases Parameter
Phase Value Phase Value
L1 0x0000 L1-L2 0x0000
L2 0x0001 L2-L3 0x0001
L3 0x0002 L3-L1 0x0002
Total III 0x0003 L1-L2-L3 0x0003
LN 0x0004
Table 57:Conguration of custom screens: Tariffs
Tariffs Parameter
(7)
Tariff Value Tariff Value
Tariff 1 0x0000 Tariff 3 0x0002
Tariff 2 0x0001 Total value of 3 tariffs 0x0003
(7)
If the variable has no tariff option, 00 will be sent.
6.3.7.19.- Manual programming of alarms
These parameters occupy 1 register each.
Table 58: Modbus memory map: Conguration variables (manual programming of alarms).
Manual programming of alarms
Configuration
variable
Address
Valid data window
Default
value
Output 1
Relay
Output 2
Relay
Output 1
Transistor
Output 1
Transistor
Programming status
(1)
4F20 4F34 4EF8 4F0C
0: Automatic
1:Manual
0
Value 4F21 4F35 4EF9 4F0D
0: Open
1:Closed
0
(1)
When programming the Programming status manually , set the output for the relays and transistors manually,
using the Value parameter. The conguration of the relay and transistor digital outputs programmed in the unit
no longer works.
The relays and transistors work in automatic mode according to the conguration programmed in the unit.
Note: The 2 registers must be written at once (as a group), otherwise it will respond with an
error.
200
CVM-B100 - CVM-B150
Instruction Manual
