Table 106 ( Continuation): Modbus memory map: Status of transistor digital outputs (Table 3).
Estado de las Salidas Digitales de Transistor : Slot 2
Variable de configuración Dirección
Not used CA62 CA76 CA8A CA9E CAB2 CAC6 CADA CAEE
Not used CA63 CA77 CA8B CA9F CAB3 CAC7 CADB CAEF
Status CA64 CA78 CA8C CAA0 CAB4 CAC8 CADC CAF0
Alarm Status CA65 CA79 CA8D CAA1 CAB5 CAC9 CADD CAF1
Note: The 14 registers must be read at once (as a group), otherwise it will respond with an
error.
Table 107: Modbus memory map: Status of transistor digital outputs (Table 4).
Transistor digital outputs: Slot3
Configuration variable
Address
Alarm
Impulse
output
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Latch kWh o Wh CE40 CE54 CE68 CE7C CE90 CEA4 CEB8 CECC
Delay in the
Connection
Wh o mWh CE42 CE56 CE6A CE7E CE92 CEA6 CEBA CECE
Delay in the
Disconnection
Factor
Energy meter
CE43 CE57 CE6B CE7F CE93 CEA7 CEBB CECF
Alarm activation
date: Year
- CE44 CE58 CE6C CE80 CE94 CEA8 CEBC CED0
Alarm activation
date: Month
- CE45 CE59 CE6D CE81 CE95 CEA9 CEBD CED1
Alarm activation
date: Day
- CE46 CE5A CE6E CE82 CE96 CEAA CEBE CED2
Alarm activation
time: Hour
- CE47 CE5B CE6F CE83 CE97 CEAB CEBF CED3
Alarm activation
time: Minutes
- CE48 CE5C CE70 CE84 CE98 CEAC CEC0 CED4
Alarm activation
time: Seconds
- CE49 CE5D CE71 CE85 CE99 CEAD CEC1 CED5
Not used CE4A CE5E CE72 CE86 CE9A CEAE CEC2 CED6
Not used CE4B CE5F CE73 CE87 CE9B CEAF CEC3 CED7
Status CE4C CE60 CE74 CE88 CE9C CEB0 CEC4 CED8
Alarm Status CE4D CE61 CE75 CE89 CE9D CEB1 CEC5 CED9
Note: The 14 registers must be read at once (as a group), otherwise it will respond with an
error.
241
Instruction Manual
CVM-B100 - CVM-B150
