Arrray 1 tipo NVT ( SNVT_str_int (37)), Unit (N/A), Resolution (1), Values (0...65,565), Bytes (31)
typedef struct {
unsigned short char_set ;
unsigned long wide_char [15] ;
} SNTV_str_int;
Name Variable type Unit
Active Power L2
nvo_ActPwrPh2 SNVT_power_kilo (28) kW L2
Code Resolution Values
08 0.1 0..6553.5
Active Power L3
Name Variable type Unit
nvo_ActPwrPh3 SNVT_power_kilo (28) kW L3
Code Resolution Values
13 0.1 0..6553.5
Cos φ III
Name Variable type Unit
nvo_Cosphi SNVT_pwr_fact (98) cos φ
Code Resolution Values
19 0.00005 -1.00000..1.00000
Active Energy (+)
Name Variable type Unit
nvo_ActEnergy SNVT_elec_kwh_I (146) kW.h(+)
Code Resolution Values
43 0.1 -214,748,364.8.. 214,748,364.6
Inductive Reactive Energy (+)
Name Variable type Unit
nvo_InductEnergy SNVT_elec_kwh_I (146) kVArL.h(+)
Code Resolution Values
44 0.1 -214,748,364.8.. 214,748,364.6
Arrray 2 tipo NVT ( SNVT_str_int (37)), Unit (N/A), Resolution (1), Values (0...65,565), Bytes (31)
typedef struct {
unsigned short char_set ;
unsigned long wide_char [15] ;
} SNTV_str_int;
Name Variable type Unit
Active Energy (+)
nvo_ActEnergy SNVT_elec_kwh_I (146) kW.h (+)
Code Resolution Values
43 0.1 -214,748,364.8.. 214,748,364.6
Inductive Reactive Energy (+)
Name Variable type Unit
nvo_InductEnergy SNVT_elec_kwh_I (146) kVArL.h(+)
Code Resolution Values
44 0.1 -214,748,364.8.. 214,748,364.6
Capacitive Reactive Energy (+)
Name Variable type Unit
nvo_CapEnergy SNVT_elec_kwh_I (146) kVArC.h(+)
Code Resolution Values
45 0.1 -214,748,364.8.. 214,748,364.6
Apparent Energy (+)
Name Variable type Unit
nvo_AppEnergy SNVT_elec_kwh_I (146) kVA.h(+)
Code Resolution Values
46 0.1 -214,748,364.8.. 214,748,364.6
277
Instruction Manual
CVM-B100 - CVM-B150
