Table 149 ( Continuation) : GSD modules (Module 9)
Mod 9
Odd harmonics current Symbol Bytes Address Units
In 9th Order Harmonic in H9 2 0BF6 %x100
In 11th Order Harmonic in H11 2 0BF8 %x100
In 13th Order Harmonic in H13 2 0BFA %x100
In 15th Order Harmonic in H15 2 0BFC %x100
Module 13
Table 150: GSD modules (Module 13)
Mod 13
Cos φ Symbol Bytes Address Units
cos φ cos φ 1 4 0E-0F x100
cos φ cos φ 2 4 1E-1F x100
cos φ cos φ 3 4 2E-2F x100
