5.1.1.2.1.- , ... Customisation screens
Figure 45 shows the screen used to customise 1 parameter.
These screens can also be congured for communications.
See “6.- INTEGRATED COMMUNICATIONS”.
Figure 45: Custom parameters screen (displays 1 parameter).
The menu in the lower area disappears after 3 seconds.
Press the
key to display the lower area again.
The lower area menu options are:
Select the parameter that will be displayed on the customisation screen.
(“5.1.1.2.1.1. Parameter selection”)
Back, returns to the home screen of the parameter customisation menu, Figure 44.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to browse the different options.
To access the option selected press the key
.
56
CVM-B100 - CVM-B150
Instruction Manual
