5.1.3.2.1.- , ... Customisation screens
Figure 79 shows the screen used to customise 4 parameters.
These screens can also be configured for communications. See
“6.- INTEGRATED
COMMUNICATIONS”
Figure 79: Custom parameters screen (displays 4 parameter).
The menu in the lower area disappears after 3 seconds.
Press the
key to display the lower area again.
The lower area menu options are:
, Select the parameter 1 that you wish to display on the customisation screen.
(See “5.1.1.2.1.1. Parameter selection”)
, Select the parameter 2 that you wish to display on the customisation screen.
(See “5.1.1.2.1.1. Parameter selection”)
, Select the parameter 3 that you wish to display on the customisation screen.
(See “5.1.1.2.1.1. Parameter selection”)
, Select the parameter 4 that you wish to display on the customisation screen.
(See “5.1.1.2.1.1. Parameter selection”)
Back, returns to the home screen of the parameter customisation menu, Figure 78.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to browse the different options.
To access the option selected press the key
.
95
Instruction Manual
CVM-B100 - CVM-B150
