Gi0/6/0/7.999, state: unresolved, Static MAC addresses: 0
Te0/1/0/2.999, state: down, Static MAC addresses: 0
List of VFIs:
RP/0/RSP1/CPU0:router#
This table lists the configuration steps (actions) and the corresponding purpose for this example:
SUMMARY STEPS
1. configure
2. interface Bundle-ether10
3. interface Bundle-ether10.999 l2transport
4. encapsulation dot1q 999
5. interface GigabitEthernet0/6/0/5
6. bundle id 10 mode active
7. interface GigabitEthernet0/6/0/6
8. bundle id 10 mode active
9. interface GigabitEthernet0/6/0/7.999 l2transport
10. encapsulation dot1q 999
11. interface TenGigE0/1/0/2.999 l2transport
12. encapsulation dot1q 999
13. l2vpn
14. bridge group examples
15. bridge-domain test-efp
16. interface Bundle-ether10.999
17. exit
18. interface GigabitEthernet0/6/0/7.999
19. exit
20. interface TenGigE0/1/0/2.999
21. Use the commit or end command.
DETAILED STEPS
Step 1 configure
Enters global configuration mode.
Step 2 interface Bundle-ether10
Creates a new bundle trunk interface.
Step 3 interface Bundle-ether10.999 l2transport
Creates an EFP under the new bundle trunk.
Step 4 encapsulation dot1q 999
Assigns VLAN ID of 999 to this EFP.
Step 5 interface GigabitEthernet0/6/0/5
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
332
Implementing Multipoint Layer 2 Services
Bridging on Ethernet Flow Points: Example
