Cisco DX650 Administration Guide

Cisco Desktop Collaboration
Experience configuration
Cisco AP configuration
EAP-FASTWEPOptional CCKMEAP-FAST
802.1X
EAP-FASTTKIPWPA
Optional CCKM
EAP-FAST with WPA
EAP-FASTAESWPA2EAP-FAST with WPA2
Auto (AKM)TKIPWPA-PSKWPA-PSK
Auto (AKM)AESWAP2-PSKWPA2-PSK
For additional information about Cisco WLAN Security, see http://www.cisco.com/en/US/products/hw/
wireless/ps430/prod_brochure09186a00801f7d0b.html.
For more information about configuring authentication and encryption schemes on APs, see the Cisco Aironet
Configuration Guide for your model and release under the following URL:
http://www.cisco.com/cisco/web/psa/configure.html?mode=prod&level0=278875243
Related Topics
Cisco Unified Wireless AP Interactions, on page 82
Authentication Methods, on page 86
Encryption Methods, on page 91
Cisco Unified Communications Manager Interaction, on page 86
VoIP Wireless Network Components, on page 82
VoIP WLAN Deployment, on page 93
VoIP WLAN Deployment
This section provides configuration guidelines for deploying Cisco Desktop Collaboration Experience devices
in the WLAN.
Supported Access Points
The Cisco Desktop Collaboration Experience is supported on both the Cisco autonomous and unified solutions.
Minimum and recommended versions are:
•
Cisco IOS Access Points (Autonomous)
◦
Minimum = 12.3(8)JEA2 or later
◦
Recommended = 12.4(10b)JA3 or later (Does not apply to Cisco Aironet Series 1100, 1140, 1200,
or 1230).
Cisco Desktop Collaboration Experience DX650 Administration Guide, Release 10.1(1)
93
VoIP WLAN Deployment

Cisco DX650 Specifications

General

Resolution	800 x 480 pixels
Audio	Wideband audio
USB Ports	2 x USB 2.0
Display	7-inch capacitive touchscreen
Camera	HD 720p
Connectivity	Ethernet, Wi-Fi
Bluetooth	Yes
SIP Protocol	Supported
Speakerphone	Full-duplex
Headset Jack	3.5 mm
Network Interfaces	10/100/1000 Ethernet
Supported Protocols	SIP
Codecs	G.722
Power over Ethernet (PoE)	Yes, IEEE 802.3af
Weight	2.2 lbs
