Value or RangeSpecification
•
microSD card slot
•
microUSB port
•
3.5-mm single plug stereo headphone jack
•
Power port
•
Network port
•
Computer port
•
Two auxiliary ports
•
HDMI port
Ports and slots, Cisco Desktop
Collaboration Experience
IEEE 802.11 a/b/g/n Wi-FiConnectivity
Android
â„¢
4.1.1 (Jelly Bean)Operating system
Cable Specifications
The Cisco Desktop Collaboration Experience includes the following:
•
RJ-45 jack for the LAN 10/100/1000BaseT connection
•
RJ-45 jack for a second 10/100/1000BaseT-compliant connection
•
AC power wall plug
Network and Computer Port Pinouts
The Cisco Desktop Collaboration Experience phone includes network and computer (access) ports, which are
used for network connectivity. They serve different purposes and have different port pinouts.
•
The Network port is the 10/100/1000 SW port.
•
The Computer (access) port is the 10/100/1000 PC port.
Network Port Connector Pinouts
The following table describes the Network port connector pinouts.
Table 3: Network Port Connector Pinouts
FunctionPin Number
BI_DA+1
Cisco Desktop Collaboration Experience DX650 Administration Guide, Release 10.1(1)
4
Cable Specifications
