Cisco DX650 Administration Guide

DescriptionItem
Identifies the asset ID assigned to Cisco Desktop Collaboration Experience
for inventory management.
LLDP Asset ID
Allows the administrator to configure the speed and function of the Cisco
Desktop Collaboration Experience table port remotely by using Cisco Unified
Communications Manager Administration.
Switch Port Remote
Configuration
Allows the administrator to configure the speed and function of the Cisco
Desktop Collaboration Experience table port remotely by using Cisco Unified
Communications Manager Administration.
PC Port Remote
Configuration
Network Statistics
The following network statistics hyperlinks on Cisco Desktop Collaboration Experience web page provide
information about network traffic on Cisco Desktop Collaboration Experience. To display a network statistics
area, access the web page for Cisco Desktop Collaboration Experience as described in the Access Web Page
for Cisco Desktop Collaboration Experience, on page 179.
•
Ethernet Information: Provides information about Ethernet traffic. The first table describes the items in
this area.
•
Access area: Provides information about network traffic to and from Cisco Desktop Collaboration
Experience. The second table describes the items in this area.
•
Network area: Provides information about network traffic to and from Cisco Desktop Collaboration
Experience. The second table describes the items in this area.
To display a network statistics area, access the web page for Cisco Desktop Collaboration Experience as
described in the Access Web Page for Cisco Desktop Collaboration Experience, on page 179, and then click
the Ethernet Information, the Access, or the Network hyperlink.
Table 45: Ethernet Information Items
DescriptionItem
Total number of packets transmitted by Cisco Desktop Collaboration ExperienceTx Frames
Total number of broadcast packets transmitted by Cisco Desktop Collaboration
Experience
Tx broadcast
Total number of multicast packets transmitted by Cisco Desktop Collaboration
Experience
Tx multicast
Total number of unicast packets transmitted by Cisco Desktop Collaboration ExperienceTx unicast
Total number of packets received by Cisco Desktop Collaboration ExperienceRx Frames
Total number of broadcast packets received by Cisco Desktop Collaboration ExperienceRx broadcast
Cisco Desktop Collaboration Experience DX650 Administration Guide, Release 10.1(1)
187
Network Statistics

Cisco DX650 Specifications

General

Resolution	800 x 480 pixels
Audio	Wideband audio
USB Ports	2 x USB 2.0
Display	7-inch capacitive touchscreen
Camera	HD 720p
Connectivity	Ethernet, Wi-Fi
Bluetooth	Yes
SIP Protocol	Supported
Speakerphone	Full-duplex
Headset Jack	3.5 mm
Network Interfaces	10/100/1000 Ethernet
Supported Protocols	SIP
Codecs	G.722
Power over Ethernet (PoE)	Yes, IEEE 802.3af
Weight	2.2 lbs
