Cisco DX650 Administration Guide

IPv4 Configuration Menu
The IPv4 configuration menu is a submenu of the Ethernet Settings menu. To access the IPv4 menu, select
IPv4 configuration on the Ethernet settings menu. The following table describes the IPv4 Configuration
menu options and, where applicable, explains how to change them.
Table 26: IPv4 Configuration Menu
To changeDescriptionOption
Tap to enable or disable option.Allows you to manually set IP
address if DHCP is not used.
Use Static IP
1
Tap Use static IP to enable.
2
Select IP address.
3
Enter IP address.
4
Tap OK.
Internet Protocol (IP) address of
Cisco Desktop Collaboration
Experience.
IP address
1
Tap Use static IP to enable.
2
Select Gateway.
3
Enter Gateway name.
4
Tap OK.
Gateway used by Cisco Desktop
Collaboration Experience.
Gateway
1
Tap Use static IP to enable.
2
Select Netmask and then
enter Netmask name.
3
Tap OK.
Netmask used by Cisco Desktop
Collaboration Experience.
Netmask
Cisco Desktop Collaboration Experience DX650 Administration Guide, Release 10.1(1)
108
Wireless and Networks Settings Menu

Cisco DX650 Specifications

General

Resolution	800 x 480 pixels
Audio	Wideband audio
USB Ports	2 x USB 2.0
Display	7-inch capacitive touchscreen
Camera	HD 720p
Connectivity	Ethernet, Wi-Fi
Bluetooth	Yes
SIP Protocol	Supported
Speakerphone	Full-duplex
Headset Jack	3.5 mm
Network Interfaces	10/100/1000 Ethernet
Supported Protocols	SIP
Codecs	G.722
Power over Ethernet (PoE)	Yes, IEEE 802.3af
Weight	2.2 lbs
