Ethernet Statistics Screen
The Ethernet statistics screen provides information about Cisco Desktop Collaboration Experience and network
performance. The following table describes the information that appears on this screen.
To display the Ethernet Statistics screen, choose About device > Status > Ethernet statistics.
To reset the Rx Frames, Tx Frames, and Rx Broadcasts statistics to 0, tap Clear.
To exit the Ethernet statistics screen, tap OK.
Table 40: Ethernet Statistics Message Information for Cisco Desktop Collaboration Experience
DescriptionItem
Number of packets received by Cisco Desktop Collaboration ExperienceRx Frames
Number of packets sent by Cisco Desktop Collaboration ExperienceTx Frames
Number of broadcast packets received by Cisco Desktop Collaboration
Experience
Rx Broadcasts
Speed and duplex for Switch PortPort 1
Speed and duplex for PC PortPort 2
Initiation file forCDP INIT
WLAN Statistics Screen
The WLAN statistics screen provides statistics about the Cisco Desktop Collaboration Experience. The
following table describes the information that appears on this screen.
To display the WLAN Statistics screen, choose About device > Status > WLAN statistics.
To exit the WLAN statistics screen, tap OK.
Table 41: WLAN Statistics on Cisco Desktop Collaboration Experience
DescriptionItem
Number of bytes transmittedtx_bytes
Number of bytes receivedrx_bytes
Number of data packets transmittedtx_packets
Number of data packets receivedrx_packets
Number of transmitted data packets droppedtx_packets_dropped
Cisco Desktop Collaboration Experience DX650 Administration Guide, Release 10.1(1)
174
