Configuring Security, Quality, and Network Features
Configuring VLAN Settings
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 165
5
Configuring the VLAN Settings
To configure VLAN settings, navigate to Admin Login > advanced > Voice >
System. Under VLAN Settings, configure the following parameters:
Parameter Description
Enable VLAN Choose Yes to enable VLAN. Choose no to
disable.
VLAN ID If you use a VLAN without Cisco Discovery
Protocol (CDP) (VLAN enabled and CDP
disabled), enter a
VLAN ID
for the IP phone.
Note that only voice packets are tagged with
the VLAN ID. Do not use 1 for the VLAN ID.
PC Port VLAN Highest
Priority
Choose No Limit, or 0-7 (default 0). The highest
priority is 7. The priority applied to all frames,
tagged and untagged. The phone modifies the
frame priority only if the incoming frame
priority is higher than this value.
Enable PC Port VLAN Tagging Enables VLAN and priority tagging on the
phone data port (802.1p/q). This feature
facilities tagging of the VLAN ID (802.1Q) and
priority bits (802.1p) of the traffic coming from
the PC port of the IP phone.
Choose Yes to enable the tagging algorithm.
Defaults to No.
PC Port VLAN ID The phone tags all of the untagged frames
coming from the PC. (It does not tag frames
with existing tags). Ranges from 0 to 4095.
Defaults to 0.
Enable CDP Enable CDP only if you are using a switch that
has CDP. CDP is negotiation-based and
determines on which VLAN the IP phone
resides.
