Configuring Lines
Assigning Busy Lamp Field, Call Pickup, or Speed Dial Functions to Unused Lines
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 48
2
where:
- fnc: function
- blf: busy lamp field
- cp: call pickup
- sub: station name
- ext or usr: extension or user (the usr and ext keywords are
interchangeable)
STEP 3 Click Submit All Changes. After the phone reboots, the phone in this example
displays the following color LEDs for the monitored lines:
• Green: Available
• Red: Busy
• Red Fast Blink: Ringing
If the phone LEDs display orange or slow blinking orange, there is a problem:
Orange indicates that the phone failed to subscribe (received a 4xx response) and
slow-blinking orange denotes an undefined problem (there might be no response
to the subscribe request, or the BLF).
When the phone is successfully configured, Bob can monitor Stephanie’s line.
When a call is ringing at Stephanie’s line, he can press line button 4 to pick it up.
Configuring Speed Dial
In this example, the assistant, Bob (extension 200), has another idle line (line 5) on
his Cisco SPA508G. He wants to speed dial his supervisor Mark (extension 400)
from that line.
To configure this feature for Bob:
STEP 1 Click Admin Login > advanced > Voice > Phone.
STEP 2 In the Line Key to configure (line 5 in this example):
a. From the Extension drop down list, choose Disabled.
b. From the Share Call Appearance drop-down list, choose private.
