Configuring Lines
Assigning Busy Lamp Field, Call Pickup, or Speed Dial Functions to Unused Lines
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 49
2
c. Enter the following string in the Extended Function field:
fnc=sd;ext=400@$PROXY
Using the following syntax:
fnc=type;ext=extension#@$PROXY
where:
- fnc: function
- sd: speed dial
- ext or usr: extension or user (the usr and ext keywords are
interchangeable)
STEP 3 Click Submit All Changes.
When the phone is successfully configured, Bob can press line button 5 to dial
Mark’s line.
Configuring DTMF Wait and Pause Parameters
Speed dial, directory, extended function, and other strings configured in the phone
can include wait (X) and pause (,) parameters that allow manual and automatic
DTMF (Dual-tone multi-frequency) signal transmission.
Syntax:
{Dial_String}[ ][,|X][DTMF_string][,|X][DTMF_string]
Where:
Dial_String—The number that the user is trying to reach. For example, 8537777 or
14088537777.
(space)—A dial termination that defines or delimits the end of the dial string. The
space is mandatory. If the phone encounters an X or a comma (,) before the space,
the characters are treated as part of dial string.
, (comma)—A 2-second pause that is inserted for each comma in the string.
X (wait)—Awaits user input and acknowledgement
• The “Waiting for more digits input. When done, press OK to continue”
message displays.
