Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 225
Configuring LED Patterns
The default LED pattern for the phone differs for different call control modes.
The table shows the default LED pattern for the SPA phones in SIP mode:
Description LED Location LED Pattern
Voice mail MWI Red
No voice mail MWI Off
Te m p o r a r y E t h e r n e t l i n k
lost
Mute Fast blink amber
Permanent Ethernet link
lost
Mute Solid amber
Registration failed Line Slow blink amber
Line disabled Line Off
Idle Line Solid green
Local Seize Line Solid red
Local Ringing Line/MWI Fast blink red
Local Held Line Slow blink red
Offhook/Proceeding Line Solid red
Connected/Local active Line Solid red
Shared line remote active
call back mode
Line Slow blink green
MuteOn Mute Solid red
Mute Off Mute Off
