Cisco SPA IP Phone Field Reference
Info Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 238
A
Phone Status
Parameter Description
Current Time Current date and time of the system; for example,
10/3/2003 16:43:00.
Elapsed Time Total time elapsed since the last reboot of the
system; for example, 25 days and 18:12:36.
Broadcast Pkts Sent Total number of broadcast packets sent.
Broadcast Bytes Sent Total number of broadcast packets received.
Broadcast Pkts Recv Total number of broadcast bytes sent.
Broadcast Bytes Recv Total number of broadcast bytes received and
processed.
Broadcast Pkts Dropped Total number of broadcast packets received but
not processed. Most codecs can handle up to 5%
random packet drops as long as the packets are
random and not in groups of two or more.
Concurrent packet drops result in voice quality
issues.
Broadcast Bytes Dropped Total number of broadcast bytes received but not
processed.
RTP Packets Sent Total number of RTP packets sent (including
redundant packets).
RTP Bytes Sent Total number of RTP packets received (including
redundant packets).
RTP Packets Recv Total number of RTP bytes sent.
RTP Bytes Recv Total number of RTP bytes received.
SIP Messages Sent Total number of SIP messages sent (including
retransmissions).
SIP Bytes Sent Total number of SIP messages received (including
retransmissions).
SIP Messages Recv Total number of bytes of SIP messages sent
(including retransmissions).
