Cisco SPA301 User Manual

Cisco SPA IP Phone Field Reference
Phone Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 305
A
Line Key LED Pattern
Does not apply to the Cisco WIP310.
Parameter Description
Idle LED The call appearance is not is in use and is
available to make a new call. Leaving this entry
blank indicates the default value of c=g.
Remote Undefined LED The shared call state is undefined (the phone is
still waiting for the state information from the
application server). Not applicable if the call
appearance is not shared. Leaving this entry blank
indicates the default value of c=r;p=d.
Local Seized LED This phone has seized the call appearance to
prepare for a new outbound call. Leaving this
entry blank indicates the default value of c=r.
Remote Seized LED The shared call appearance is seized by another
phone. Not application if the call appearance is
not shared. Leaving this entry blank indicates the
default value of c=r;p=d.
Local Progressing LED This phone is attempting on this call appearance
an outgoing call that is in proceeding (i.e. the
called number is ringing). Leaving this entry blank
indicates the default value of c=r.
Remote Progressing LED Another phone is attempting on this shared call
appearance an outbound call that is progressing.
Not applicable if the call appearance is not
shared. Leaving this entry blank indicates the
default value of c=r;p=d.
Local Ringing LED The call appearance is ringing. Leaving this entry
blank indicates the default value of c=r;p=f.
Remote Ringing LED The shared call appearance is in ringing on
another phone. Not applicable if the call
appearance is not shared. Leaving this entry blank
indicates the default value of c=r;p=d.
