Cisco SPA IP Phone Field Reference
Info Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 239
A
Ext Status
The following parameters show for each extension on the phone.
SIP Bytes Recv Total number of bytes of SIP messages received
(including retransmissions).
External IP External IP address used for NAT mapping.
Operational VLAN ID ID of the VLAN currently in use if applicable.
NOTE Not applicable to Cisco WIP310.
SW Port (Cisco SPA300
Series and Cisco SPA500
Series)
Displays the type of Ethernet connection from the
IP phone to the switch.
PC Port (Cisco SPA303
and Cisco SPA500 Series)
Indicates whether the link from the IP phone to a
device plugged into the PC port on the phone is
up or down.
Parameter Description
Parameter Description
Registration State Shows “Registered” if the phone is registered,
“Not Registered” if the phone is not registered to
the ITSP.
Last Registration At Last date and time the line was registered.
Next Registration In Number of seconds before the next registration
renewal.
Message Waiting Indicates whether the phone user has a new voice
mail waiting: Yes or No. This is updated when
voice mail notification is received.
Mapped SIP Port Port number of the SIP port mapped by NAT.
