Cisco SPA IP Phone Field Reference
Info Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 240
A
Line/Call Status
The following parameters show for each line and call on the phone.
Parameter Description
Call State Status of the call.
Tone Type of tone used by the call.
Encoder Codec used for encoding.
Decoder Codec used for decoding.
Type Direction of the call.
Remote Hold Indicates whether the far end has placed the call
on hold.
Callback Indicates whether the call was triggered by a call
back request.
Peer Name Name of the internal phone.
Peer Phone Phone number of the internal phone.
Duration Duration of the call.
Packets Sent Number of packets sent.
Packets Recv Number of packets received.
Bytes Sent Number of bytes sent.
Bytes Recv Number of bytes received.
Mapped RTP Port The port mapped for Real Time Protocol traffic for
the call.
Media Loopback If the call is a loopback call, displays the loopback
mode (source or mirror) and type (media or
packet). If the call is not loopback, the field appears
blank.
Decode Latency Number of milliseconds for decoder latency.
Jitter Number of milliseconds for receiver jitter.
