Cisco SPA IP Phone Field Reference
Ext Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 330
A
Voice Quality
Report Address
For configuration of a SIP event package, SIP PUBLISH,
that enables the collection and reporting of metrics that
measure the quality for VoIP sessions. Voice call quality
information derived from RTCP-XR and call information
from SIP is conveyed from a User Agent in a session to the
third party in SIP PUBLISH method.
To configure, first configure RTCP-XR (see RTP
Parameters). Configure the RTCP Tx Interval. In the Voice
Quality Report Address field, enter the name of the
collector that collects the statistics from the SIP PUBLISH
events. For example, enter
collector@
fully-qualified-domain-name
(collector@reports.cisco.com) or
collector
@
IP
-
address
(collector@192.168.5.1).
After RTCP-XR feature is enabled, the call status
information is updated on Voice > Info during an active call.
Additionally, RTCP-XR packets containing a voice metrics
block report are sent with the interval specified in the
RTCP Tx Interval. When the call session is ended, a SIP
PUBLISH with voice metrics information is sent to the
collector endpoint. This parameter supports a full SIP URI.
Examples of valid addresses are:
• collector@domain.com
• 123.collect@123.123.123.123:5555
• 5678@domain.com:5656
For example to configure for extension 1, edit the phone
configuration file as follows:
<Voice_Quality_Report_Address_1_
ua="na">collector@domain.com
</Voice_Quality_Report_Address_1_>
<Voice_Quality_Report_Address_1_
ua="na">123.collect@123.123.123.123:5555
</Voice_Quality_Report_Address_1_>
<Voice_Quality_Report_Address_1_
ua="na">5678@domain.com:5656
</Voice_Quality_Report_Address_1_>
Parameter Description
