Cisco SPA301 User Manual

Cisco SPA IP Phone Field Reference
Ext Tab
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 347
A
DTMF Tx Volume for
AV T Pa cket
Allows you to manually configure the AVT Tx volume.
The value of this parameter is inserted into the volume
field of the payload in the AVT packet.
Values are based on the AVT specification as
described in RFC 2833,
RTP Payload for DTMF Digits,
Te l e p h o n y To n e s a n d Te l e p h o n y S i g n a l s
. According to
RFC 2833, the volume field is represented by 6 bits,
and describes the power level of the tone, expressed
in dBm0 after dropping the sign.
Valid range for this parameter is 0 to 63. If the
provisioned value is negative, it will be negated first.
Thereafter, if the value is beyond the high limit of 63, it
will be clipped to 63.
The default value is 0, and is the recommended
setting. However, some gateways do not accept this
volume setting. If the gateway does not accept the
value of 0, the DTMF tone is not relayed to the remote
end. As a workaround for the phone to interoperate
with those gateways, you can change the value to a
value greater than 0.
Use Remote Pref
Codec
If set to yes, the phone communicates using the
remote phone preferred codec. If set to no, the Cisco
IP phone communicates using its own preferred codec
(as indicated in the Preferred Codec field and in the
SDP by order of preferences). The default vale is no.
Codec Negotiation When set to Default, the Cisco IP phone responds to
an Invite with a 200 OK response advertising the
preferred codec only. When set to List All, the Cisco IP
phone responds listing all the codecs that the phone
supports. The default value is Default, or to respond
with the preferred codec only.
Parameter Description
