Customizing Standard Features
Customizing Phone Softkeys
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 75
3
Softkey Speed Dial Extension Example
This example shows how to configure the Cisco SPA525G or Cisco SPA525G2
phone with softkey that, when pressed, dials the Sales Department extension
(200). You want this button to display on the far lower left of the IP phone screen
when the phone is idle, when the phone is off hook, or when the phone is
connected on a call. You want the outbound call (that is going to the speed dial) to
originate from the second extension on the user phone, not the primary extension.
STEP 1 Click Admin Login > advanced > Voice > Phone.
STEP 2 Under Programmable Softkey Enable, choose yes to enable.
STEP 3 In the Programmable Softkeys section, edit the following:
• PSK1: fnc=sd;ext=200@$PROXY;vid=2;nme=Sales
• Idle Key List: Edit the field to add psk1|1 to the beginning of the string; for
example:
psk1|1;em_login;acd_login;acd_logout;avail;unavail;
redial;dir;cfwd;dnd;lcr;pickup;gpickup;unpark;em_logout;
• Off Hook Key List: Edit the field to add psk1|1 to the beginning of the string;
for example:
psk1|1;option;redial;dir;cfwd;dnd;lcr;unpark;pickup;
gpickup;
• Connected Key List: Edit the field to add psk1|1 to the string, editing the
existing
softkeyname |1 to PSK1. For example, the original string:
hold|1;endcall|2;conf|3;xfer|4;bxfer;confLx;xferLx;park;p
hold;flash;
becomes:
psk1|1;hold|2;endcall|3;conf|4;xfer;bxfer;confLx;xferLx;
park;phold;flash
STEP 4 Click Submit All Changes. The Sales speed dial softkey is displayed in the lower
left of the IP phone screen when the phone is idle, when the phone is connected
on a call, and when the phone is off hook.
