Customizing Standard Features
Configuring LDAP for the Cisco SPA300 Series and Cisco SPA500 Series IP Phones
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 98
3
For more information on LDAP, including troubleshooting information, see the
Configuring LDAP Directory Search on SPA SIP IP Phones Application Note,
available from http://www.cisco.com/web/partners/sell/smb/products/
voice_and_conferencing.html#~vc_technical_resources
(partner log on required).
LDAP Display Attrs Enter the format of LDAP results display on phone where:
•a—Attribute name
• cn—Common name
• sn—Surname (last name)
• telephoneNumber—Phone number
•n—Display name
For example,
n=Phone causes Phone: to be displayed
in front of the phone number of an LDAP query result when
the detail soft button is pressed.
t—type
When
t=p, t is of type phone number and the retrieved
number can be dialed. Only one number can be made
dialable. If two numbers are defined as dialable, only the
first number is used. For example,
a=ipPhone, t=p;
a=mobile, t=p;
This example results in only the ipPhone number being
dialable and the mobile number is ignored.
• p—phone number
When p is assigned to a type attribute, example
t=p, the
the retrieved number is dialable.
LDAP Number Mapping
With the LDAP number mapping you can manipulate
the number that was retrieved from the LDAP server.
For example, you can append
9 to the number if your
dial plan requires a user to enter 9 before dialing.
Add the 9 prefix by adding (<:9>xx.>) to the LDAP
Number Mapping field. For example, 555 1212 will
become 9555 1212.
Can be blank if not needed.
If you do not manipulate the number in this fashion, a user
can use the Edit Dial feature to edit the number before
dialing out.
Parameter
Description
