Cisco TelePresence SX80 Administrator Guide
Control a local camera
Sign in to the web interface and navigate to Call Control.
Prerequisites
• The Video > Input > Connector n > CameraControl >
Mode setting is switched On .
• The camera has pan, tilt or zoom functionality.
Move the camera using the pan/tilt/zoom controls
1. Choose which camera to control in the Main Source drop
down list.
2. Click the camera icon to open the camera control
window.
Video snapshots from the room are only displayed for
video systems that have the Remote Monitoring option.
3. Use the left and right arrows to pan the camera; the up
and down arrows to tilt it; and + and - to zoom in and out.
Only relevant controls appear in the window.
Move the camera to a preset position
1. Choose which camera to control in the Main Source
drop down list.
2. Click Presets... to open a list of available presets.
If no presets are defined, the button is disabled and
named No presets.
3. Click a preset’s name to move the camera to the preset
position.
4. Click OK to close the window.
You cannot use the web interface to define a preset;
you should use the Touch controller.
Main Source drop down list
Choose which camera to control from
the drop down list.
Automatically refresh snapshots
Snapshot area
Shows snapshots of the selected main input source.
Only available on video systems that have the
Remote Monitoring option.
