Cisco TelePresence SX80 Administrator Guide
In the following pages you will find a complete list of the system
settings which are configured from the Setup > Configuration
page on the web interface.
Open a web browser and enter the IP address of the video
system then sign in.
How to find the IP address
1. Select the settings icon (cogwheel) in the status bar of
the Touch controller.
2. Select Settings > System Information.
Audio settings ................................................................................................................. 88
Audio DefaultVolume ........................................................................................................... 88
Audio Input HDMI [1..3] Level .............................................................................................. 89
Audio Input HDMI [1..3] Mode ............................................................................................. 89
Audio Input HDMI [1..3] VideoAssociation MuteOnInactiveVideo ........................................ 89
Audio Input Line [1..4] Channel............................................................................................ 90
Audio Input Line [1..4] Equalizer ID ...................................................................................... 90
Audio Input Line [1..4] Equalizer Mode ................................................................................ 90
Audio Input Line [1..4] Level ................................................................................................ 90
Audio Input Line [1..4] Mode ................................................................................................ 91
Audio Input Line [1..4] VideoAssociation MuteOnInactiveVideo .......................................... 90
Audio Input Line [1..4] VideoAssociation VideoInputSource ............................................... 90
Audio Input Microphone [1..8] EchoControl Dereverberation .............................................. 91
Audio Input Microphone [1..8] EchoControl Mode .............................................................. 91
Audio Input Microphone [1..8] EchoControl NoiseReduction .............................................. 91
Audio Input Microphone [1..8] Equalizer ID .......................................................................... 91
Audio Input Microphone [1..8] Equalizer Mode .................................................................... 91
Audio Input Microphone [1..8] Level .................................................................................... 92
Audio Input Microphone [1..8] Mode ................................................................................... 92
Audio Input Microphone [1..8] Type ..................................................................................... 92
Audio Input Microphone [1..8] VideoAssociation MuteOnInactiveVideo ............................. 92
Audio Input Microphone [1..8] VideoAssociation VideoInputSource ................................... 92
Audio MicrophoneReinforcement Gain ............................................................................... 89
Audio MicrophoneReinforcement Input Microphone [1..8] Mode ....................................... 88
Audio MicrophoneReinforcement Output Line [1..4] Mode ................................................. 88
Audio Microphones Mute Enabled ...................................................................................... 88
Audio Output HDMI [1..2] Level ........................................................................................... 92
Audio Output HDMI [1..2] Mode ........................................................................................... 93
Audio Output Line [1..6] Channel......................................................................................... 93
Audio Output Line [1..6] Delay DelayMs .............................................................................. 93
Audio Output Line [1..6] Delay Mode ................................................................................... 93
Audio Output Line [1..6] Equalizer ID ................................................................................... 93
Audio Output Line [1..6] Equalizer Mode ............................................................................. 93
Audio Output Line [1..6] Level ............................................................................................. 94
Audio Output Line [1..6] Mode ............................................................................................. 94
Audio SoundsAndAlerts RingTone ...................................................................................... 89
Audio SoundsAndAlerts RingVolume .................................................................................. 89
Overview of the system settings
Introduction
Configuration
Peripherals
Maintenance
System settings
Appendices

System settings

Cisco TelePresence SX80 Specifications

General

Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.262, H.263, H.264, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.722, G.722.1, G.729ab
Noise reduction	Yes
HDMI ports quantity	5
DVI-D ports quantity	1
USB 2.0 ports quantity	2
Product color	Silver
Rack capacity	1U
Number of persons	0 person(s)
Analog signal format system	NTSC, PAL
Security algorithms	HTTPS, SSH
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	SIP, H.323, ISDN, TCP/IP, DHCP, QoS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	-
Image sensor size	- \

Weight and Dimensions

Depth	309.8 mm
Width	442 mm
Height	44 mm
Weight	3650 g
