Cisco TelePresence SX80 Administrator's Guide

D15328.04 SX80 Administrator Guide CE8.2, OCTOBER 2016. www.cisco.com — Copyright © 2016 Cisco Systems, Inc. All rights reserved.
178
Cisco TelePresence SX80 Administrator Guide
PRODUCT COMPATIBILITY
Fully compatible with standards-compliant
telepresence and video systems
SOFTWARE COMPATIBILITY
• Cisco TelePresence Software Version TC7.1 or later
• Collaboration Endpoint Software Version 8.0 or later
BANDWIDTH
H.323 and SIP up to 6 Mbps point-to-point
Up to 6 Mpbs total MultiSite bandwidth
MINIMUM BANDWIDTH FOR RESOLUTION / FRAME
RATE H.264
• 720p30 from 768 kbps
• 720p60 from 1152 kbps
• 1080p30 from 1472 kbps
• 1080p60 from 2560 kbps
FIREWALL TRAVERSAL
• Cisco TelePresence Expressway technology
• H.460.18 and H.460.19 firewall traversal
• SIP ICE (Interactive Connectivity Establishment)
VIDEO STANDARDS
• H.261
• H.263
• H.263+
• H.264
• H.265 (SIP)
VIDEO FEATURES
• Advanced screen layouts
• Local auto-layout
VIDEO INPUTS FIVE INPUTS
Extended Display Identification Data (EDID)
HDCP is not supported
Three HDMI inputs
*
Support formats up to maximum 1920 × 1080@60 fps,
including:
• 1920 × 1080@60 and 59.94 Hz (1080p60)
• 1920 × 1080@50 Hz (1080p50)
• 1920 × 1080@30 and 29.97 Hz (1080p30)
• 1920 × 1080@25 Hz (1080p25)
• 1920 × 1080@24, and 23.97 Hz (1080p24)
• 1280 × 720@60, and 59.94 Hz (720p60)
• 1280 × 720@50 Hz (720p50)
• 720 × 480@60, and 59.94 Hz (480p60)
• 640 × 480@60 Hz (480p60)
• 1280 × 1024@60, and 75 Hz (SXGA)
• 1024 × 768@60, 70, 75, and 85 Hz (XGA)
• 800 × 600@56, 60, 72, 75, and 85 Hz (SVGA)
• 1920 × 1200@50 and 60 Hz (WUXGA)
• 1680 × 1050@60 Hz (WSXGA+)
• 1440 × 900@60 Hz (WXGA+)
• 1280 × 768@60 Hz (WXGA)
One DVI-I input
Analog (VGA or YPbPr); support formats up to
maximum 1920 × 1080@60 fps (1080p60), including:
• 1920 × 1080@60 Hz (1080p)
• 1280 × 720@60 Hz (720p)
• 1280 × 1024@60 and 75 Hz (SXGA)
• 1280 × 960@60 Hz
• 1024 × 768@60, 70, 75, and 85 Hz (XGA)
• 1680 × 1050@60 Hz (WSXGA+)
• 1440 × 900@60 Hz (WXGA+)
• 1280 × 800@60 Hz (WXGA)
• 1280 × 768@60 Hz (WXGA)
Digital (DVI-D); support formats up to maximum
1920 × 1080@60 fps, including:
• 1920 × 1080@60, 59.94 Hz (1080p60)
• 1920 × 1080@50 Hz (1080p50)
• 1920 × 1080@30, 29.97 Hz (1080p30)
• 1920 × 1080@25 Hz (1080p25)
• 1920 × 1080@24, 23.97 Hz (1080p24)
• 1280 × 720@60, 59.94 Hz (720p60)
• 1280 × 720@50 Hz (720p50)
• 720 × 480@60, 59.94 Hz (480p60)
• 640 × 480@60 Hz (480p60)
• 1280 × 1024@60, 75 Hz (SXGA)
• 1024 × 768@60, 70, 75, 85 Hz (XGA)
• 800 × 600@56, 60, 72, 75, 85 Hz (SVGA)
• 1680 × 1050@60 Hz (WSXGA+)
• 1440 × 900@60 Hz (WXGA+)
• 1280 × 768@60 Hz (WXGA)
One Composite/S-Video Input (BNC Connectors)
• PAL/NTSC
VIDEO OUTPUTS THREE OUTPUTS
Two HDMI outputs
*
and one DVI-I output
Supports formats up to maximum
1920 × 1080@60fps (1080p60), including:
• 1920 × 1080@60 Hz (1080p60)
• 1920 × 1080@50 Hz (1080p50)
• 1280 × 720@60 Hz (720p60)
• 1280 × 720@50 Hz (720p50)
VESA Monitor Power Management
Extended Display Identification Data (EDID)
Supports encode/decode video formats up to
maximum 1920 × 1080@60 fps (HD1080p60),
including:
• 176 × 144@30 frames per second (fps) (QCIF)
• 352 × 288@30 fps (CIF)
• 512 × 288@30 fps (w288p)
• 576 × 448@30 fps (448p)
• 768 × 448@30 fps (w448p)
• 704 × 576@30 fps (4CIF)
• 1024 × 576@30 fps (w576p)
• 1280 × 720@30 fps (720p30)
• 1920 × 1080@30 fps (1080p30)
• 640 × 480@30 fps (VGA)
• 800 × 600@30 fps (SVGA)
• 1024 × 768@30 fps (XGA)
• 1280 × 1024@30 fps (SXGA)
• 1280 × 768@30 fps (WXGA)
• 1440 × 900@30 fps (WXGA+)
• 1680 × 1050@30 fps (WSXGA+)
• 512 × 288@60 fps (w288p60)
• 768 × 448@60 fps (w448p60)
• 1024 × 576@60 fps (w576p60)
• 1280 × 720@60 fps (720p60)
• 1920 × 1080@60 fps (1080p60)
AUDIO STANDARDS
• 64 kbps and 128 kbps AAC-LD
• G.722
• G.722.1
• G.711
• G.729AB
AUDIO FEATURES
• High quality 20 kHz audio
• Eight separate acoustic echo cancellers
• Eight-port audio mixer
• Eight assignable equlaizers
• Automatic gain control (AGC)
• Automatic noise reduction
• Active lip synchronization
AUDIO INPUTS 15 INPUTS
• Eight microphones, 48 V phantom powered,
Euroblock connector, each with separate echo
cancellers and noise reduction; all microphones can
be set for balanced line level
• Four balanced line level inputs, Euroblock connector
• Three HDMI inputs, digital, stereo (from PC/DVD)
*
AUDIO OUTPUTS EIGHT OUTPUTS
• Six balanced line level outputs, Euroblock connector
• Two HDMI outputs
*
DUAL STREAM
• H.239 (H.323) dual stream
• BFCP (SIP) dual stream
• Support for resolutions up to 1080p30, independent
of main stream resolution
MULTIPOINT SUPPORT
• Five-way embedded SIP/H.323 MultiPoint, ref.
MultiSite
• Cisco Ad-Hoc Conferencing (requires Cisco
Unified Communications Manager (CUCM), Cisco
TelePresence Server and Conductor)
• Cisco Conferencing Active Control
*
HDMI version 1.4
Technical specification (page 1 of 3)
Introduction
Configuration
Peripherals
Maintenance
System settings
Appendices

Appendices

Cisco TelePresence SX80 Specifications

General

Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.262, H.263, H.264, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.722, G.722.1, G.729ab
Noise reduction	Yes
HDMI ports quantity	5
DVI-D ports quantity	1
USB 2.0 ports quantity	2
Product color	Silver
Rack capacity	1U
Number of persons	0 person(s)
Analog signal format system	NTSC, PAL
Security algorithms	HTTPS, SSH
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	SIP, H.323, ISDN, TCP/IP, DHCP, QoS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	-
Image sensor size	- \

Weight and Dimensions

Depth	309.8 mm
Width	442 mm
Height	44 mm
Weight	3650 g
