Chapter 5 Parts Lists
5-33 CL-E700 series
PARTS LIST for CL-E700 series TITLE: Unit Ribbon Sheet No. 1/3
Drawing No. 8 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
8-1 SA Ribbon Tension Unit R PPG30002-0 1
-2 SA2 Ribbon Unit Fan - 1 (Ref. Drawing No. 9)
-3 Spring Ribbon Return R PJG60085-0 1
-4 Holder Clutch Shaft PBE40025-0 1
-5 SA Ribbon Control PCB PPS00161-0 1
-6 SA Ribbon Motor F PPF80004-0 1
-7 SA Ribbon Cable PPS30048-0 1
-8 Cover Ribbon Gear PBA00099-0 1
-9 Shaft Tension Adjust JM32011-0 1
-10 Lever F Tension Adjust JM34118-0 1
-11 Holder2 Tension Spring PBE00062-0 1
-12 Spring Ribbon Tension PJG60082-0 2
-13 Cam Tension Base Adjust JM39201-0 2
-14 SA Ribbon Sensor PPS90029-0 1
-15 Cover RBN Tension Adjust JM34112-0 1
-16 Bush Ribbon Roller PBE40018-0 2
-17 SA Ribbon Sensor Frame F PPC70008-0 1
-18 SA Ribbon Tension Shaft F PPM10004-0 1
-19 Sheet Static Eliminator 621 JM29909-0 1
-20 Holder Ribbon Shaft Encoder PBE00065-0 1
