Citizen CL-E700 Series

Chapter 5 Parts Lists
CL-E700 series 5-34
PARTS LIST for CL-E700 series TITLE: Unit Ribbon Sheet No. 2/3
Drawing No. 8 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
8-21 SA Ribbon Encoder PPS90030-0 1
-22 SA Ribbon Frame (with Support) PPC60035-0 1
-23 Gear 5F Ribbon JM30206-0 1
-24 Spring Ribbon Return PJG60107-0 1
-25 SA Holder R Shaft JM31701-0 1
-26 Gear 4 Ribbon JM30203-1 1
-27 Gear 2 Ribbon JM30202-0 1
-28 Gear 3 Ribbon JM30205-0 1
-29 Gear Reduction Ribbon 1 PBF00079-0 1
-30 Catch Ribbon Holder JM34203-0 2
-31 Knob Ribbon Unit JM34204-0 1
-32 Roller Ribbon Guide R PCM10012-0 1
-33 Bushing Ribbon Guide R PBE40026-0 1
-34 Plate Ribbon Guide Roller PAC70069-0 1
-35 Plate Ribbon Washer JM34122-0 2
-36 Knob Tension Adjust JM34207-0 1
-37 Screw BH M3.0x4 (NI) E00530-040WF 10
-38 Screw PH(PW) M2.0x8 (NI) E00620-080WF 1
-39 Screw No0 PH(4-0.3) M2x3 (NI) E03920-030WF 10
-40 Screw BH M3.0x3 (NI) E00530-030WF 8
