Citizen CL-E700 Series

Chapter 2 Operating Principles
2-3. Operation Panel
CL-E700 series 2-60
Submenu Name
[Factory Mode Settings
Menu name]
Adjustable Value
(Default Value)
Description
Mach Hor Pos
[Machine Horizontal Pos.]
-16 to +32dot
(+008 dot)
Electrically shifts the head position to the right or
left side.
(-2 to +4 mm, -0.08 to +0.16 inches)
Auto Cal Mode
[AutoCal Mode]
On/Off
(On)
Automatically controls the light amount of each
media sensor.
Through LED
[See Through Sensor]
0.0 to 3.3V
(0.0 V)
This menu is effective when “Auto Cal Mode” is
set to OFF. The light amount emitted from the
light emitter can be changed when “Media
Sensor” submenu is set to “See Through”.
Reflect LED
[Reflect Sensor]
0.0 to 3.3V
(0.0 V)
This menu is effective when “Auto Cal Mode” is
set to OFF. The light amount emitted from the
light emitter can be changed when “Media
Sensor” submenu is set to “Reflect”.
Thru Sensitiv
[See Through Sensitivity]
Low, Medium,
High (Low)
This menu is effective when “Auto Cal Mode”
submenu is set to OFF. The sensitivity of
transparent sensor can be changed in three
steps.
Refl Sensitiv
[Reflect Sensitivity]
Low, Medium,
High (Low)
This menu is effective when “Auto Cal Mode”
submenu is set to OFF. The sensitivity of
reflective sensor can be changed in three steps.
Cal Thru Level
[Through Cal Level]
0.01 to 3.30V
(2.30V)
Performs sensitivity adjustment for “Media
Sensor” submenu “See Through”. The amount
of light received is set to “2.30V”.
Cal Refl Level
[Reflect Cal Level]
0.01 to 3.30V
(2.10 V)
Performs sensitivity adjustment for “Media
Sensor” submenu “Reflect”. The amount of light
received is set to “2.10V”.
Cal None Level
[SensNone Cal Level]
0.01 to 3.30V
(2.05 V)
Performs sensitivity adjustment for “Media
Sensor” submenu “None”. The amount of light
received is set to “2.05V”.
Peel Sens Level 0.01 to 3.30V
(1.50 V)
Sets the threshold value for the peel sensor.
Cont Paper Sens Through/Reflect
(Reflect)
When continuous media is used, selects the
sensor type to be used for detecting paper end.
Darkness Rate
[Darkness Rate]
High, Low
(High)
Selects the rate to increase or decrease the
print darkness.
Dbl Heat Menu
[Double Heat Menu]
On/Off
(Off)
Selects whether to display the menu of “Double
Heat” or not.
TT Hot HeatRate
[TT Hot HeatRate Adjust]
-1.0 to +1.0%
(0.0%)
In TT (Thermal Transfer) mode, adjusts the head
temperature compensation coefficient for the
head temperature 25C (77F) and higher.
To increase the print darkness, increase the
value.
