Setup procedures (part 1)
5-28
9390 Reference manual
Action
Notes
7.
Press
F2
The display shows:
EXIT
ENTER
Clone T
ransceiver
Connect cable and
press F2 to begin
8.
To start the transfer of
information, press
F2
The display shows:
Cloning transceiver
.
After about two minutes,
cloning finishes and the master
transceiver ‘beeps’ twice. The
display shows:
Please remove the
cloning cable to
return to the Setup
Menu.
9.
Disconnect the cable and
switch off both
transceivers.
