Codan NGT 2010 RF User Manual

15 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05265-001 - Application Processor PCB
BOM Revision
Date Valid On
C26 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C27 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C28 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C29 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C30 22p 5% 100V NPO 0603
NiSn
Philips 0603CG220J0B200 46-12200-083 1
C31 22p 5% 100V NPO 0603
NiSn
Philips 0603CG220J0B200 46-12200-083 1
C32 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C33 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C34 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C35 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C36 Not Fitted Codan **-00000-001 99-00000-001 1
C37 Not Fitted Codan **-00000-001 99-00000-001 1
C38 Not Fitted Codan **-00000-001 99-00000-001 1
C39 Not Fitted Codan **-00000-001 99-00000-001 1
C40 Not Fitted Codan **-00000-001 99-00000-001 1
C41 Not Fitted Codan **-00000-001 99-00000-001 1
C42 Not Fitted Codan **-00000-001 99-00000-001 1
C43 Not Fitted Codan **-00000-001 99-00000-001 1
C44 Not Fitted Codan **-00000-001 99-00000-001 1
C45 Not Fitted Codan **-00000-001 99-00000-001 1
C46 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C47 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C48 Not Fitted Codan **-00000-001 99-00000-001 1
C49 Not Fitted Codan **-00000-001 99-00000-001 1
C50 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C51 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C52 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C53 Not Fitted Codan **-00000-001 99-00000-001 1
C54 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
D1 Diode, Schottky 40V 3A
SMC
Motorola MBRS340T3 MBRS340T3 1
H1 Not Fitted Codan **-00000-001 99-00000-001 1
H2 Not Fitted Codan **-00000-001 99-00000-001 1
IC1 Serial Number, 48 bit
SOT223
Dallas DS2401Z YM-02401-700 1
IC2 Monitor, Micro
SOIC8
Dallas DS1232LPS-2 XD-01232-700 1
IC3 Digital Signal Processor
QFP144
Texas Instruments TMS320C32PCM40 YP-32032-700 1
IC4 Micro prgmd, RFU Master I/O MEMEC 90-20590-001 90-20590-001 1
Page 2 of 6
