Codan NGT 2010 RF - Page 283

15 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05265-001 - Application Processor PCB
BOM Revision
Date Valid On
IC5 Voice-Band ADC & DAC 14BIT
PLCC28
Texas Instruments TLC320AC01CFN YN-32001-900 1
IC6 Reg, Voltage +5V 1A Switch National Semiconduct LM2575T-5.0 XB-02575-400 1
IC7 Amp, Oper Dual CMOS
SOIC8
National Semiconduct LMC662CM XA-00662-700 1
IC11 FLASH prgmd, RF-Unit D0-
D15
Braemac 90-20595-101 90-20595-101 1
IC12 FLASH prgmd, RF-Unit D16-31 Braemac 90-20595-201 90-20595-201 1
IC13 SRAM, CMOS 256k x 16 Bit
20ns SOJ44
Alliance AS7C4098-20JC YM-74098-700 1
IC14 SRAM, CMOS 256k x 16 Bit
20ns SOJ44
Alliance AS7C4098-20JC YM-74098-700 1
IC15 EPLD prgmd, RFU Address
Decoder
Codan 90-20589-001 90-20589-001 1
IC16 FLASH, 512k x 8 Bit 75ns
PLCC32
AMD AM29F040B-75JC YM-29040-900 1
IC17 Cntlr, CAN bus 2,0B
SOIC28
Philips SJA1000T/N1 YL-81000-700 1
L1 Ind, 680uH Switched Supply Coilcraft DS5022P-684 43-82680-000 1
L2 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L3 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Not Fitted Codan **-00000-001 99-00000-001 1
P2 Not Fitted Codan **-00000-001 99-00000-001 1
P3 Not Fitted Codan **-00000-001 99-00000-001 1
P4 Not Fitted Codan **-00000-001 99-00000-001 1
P5 Header (P) 26way 2row Boxed
SMD
Neltron 2316SMD-26G-CAP-TR 60-00260-002 1
P6 Not Fitted Codan **-00000-001 99-00000-001 1
P7 Not Fitted Codan **-00000-001 99-00000-001 1
P8 Socket, 16way 1row ZIF 1mm
Pitch SMD
Global Shine GS008-16-G-1 60-00163-004 1
R1 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R2 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R3 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R4 2,7k Ohm 5% 0,06W 0603 Philips 2322 702 60272 40-32700-121 1
R5 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R6 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R7 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R8 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R9 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R10 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R11 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
