Codan NGT 2010 RF User Manual

15 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05265-001 - Application Processor PCB
BOM Revision
Date Valid On
R12 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R13 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R14 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R15 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R16 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R17 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R18 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R19 Not Fitted Codan **-00000-001 99-00000-001 1
R20 Not Fitted Codan **-00000-001 99-00000-001 1
R21 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R22 33 Ohm 5% 0,06W 0603 Philips 2322 702 60339 40-13300-121 1
R23 33 Ohm 5% 0,06W 0603 Philips 2322 702 60339 40-13300-121 1
R24 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R25 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R26 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R27 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R28 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R29 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R30 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R31 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R32 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R33 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R34 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R35 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R36 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R37 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R38 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R39 33 Ohm 5% 0,06W 0603 Philips 2322 702 60339 40-13300-121 1
R40 33 Ohm 5% 0,06W 0603 Philips 2322 702 60339 40-13300-121 1
R41 33 Ohm 5% 0,06W 0603 Philips 2322 702 60339 40-13300-121 1
Page 4 of 6
