Codan NGT 2010 RF - Page 299

12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
R211 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R212 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R213 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R214 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R215 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R216 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R217 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R218 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R219 1M Ohm 5% 0,125W 1206 Philips 2322 711 61105 40-61000-101 1
R220 68k Ohm 5% 0,125W 1206 Philips 2322 711 61683 40-46800-101 1
R221 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R222 0 Ohm Jumper 1206 Philips 2322 711 90001 40-00001-101 1
R223 Not Fitted Codan **-00000-001 99-00000-001 1
R224 Not Fitted Codan **-00000-001 99-00000-001 1
R225 1,8k Ohm 5% 0,125W 1206 Philips 2322 711 61182 40-31800-101 1
R226 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R227 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R228 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R229 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R230 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R231 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R232 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R233 6,8k Ohm 5% 0,125W 1206 Philips 2322 711 61682 40-36800-101 1
R234 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R235 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R236 5,6k Ohm 5% 0,125W 1206 Philips 2322 711 61562 40-35600-101 1
R237 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R238 150 Ohm 5% 0,125W 1206 Philips 2322 711 61151 40-21500-101 1
R239 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R240 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
