Codan NGT 2010 RF User Manual

12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
R241 1M Ohm 5% 0,125W 1206 Philips 2322 711 61105 40-61000-101 1
R242 220 Ohm 5% 0,125W 1206 Philips 2322 711 61221 40-22200-101 1
R243 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R244 220 Ohm 5% 0,125W 1206 Philips 2322 711 61221 40-22200-101 1
R245 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R246 220 Ohm 5% 0,125W 1206 Philips 2322 711 61221 40-22200-101 1
R247 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R248 6,8k Ohm 5% 0,125W 1206 Philips 2322 711 61682 40-36800-101 1
R249 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R250 330 Ohm 5% 0,125W 1206 Philips 2322 711 61331 40-23300-101 1
R252 680 Ohm 10% NTC
Thermistor
Philips 2322 640 63681 41-02684-642 1
R253 470 Ohm 5% 0,125W 1206 Philips 2322 711 61471 40-24700-101 1
R254 5,6k Ohm 5% 0,125W 1206 Philips 2322 711 61562 40-35600-101 1
R255 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R256 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R257 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R258 8,2k Ohm 5% 0,125W 1206 Philips 2322 711 61822 40-38200-101 1
R259 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R260 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R261 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R262 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R263 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R264 82k Ohm 5% O,125W 1206 Philips 2322 711 61823 40-48200-101 1
R265 0 Ohm Jumper 1206 Philips 2322 711 90001 40-00001-101 1
R266 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R267 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R268 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R269 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R270 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
Page 14 of 21
