11 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05416-001 - Filter & Control PCB
BOM Revision
Date Valid On
D12 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D14 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
IC1 Reg, Voltage +10V IC National Semiconduct LM2940T-10 XB-02940-402 1
IC2 Micro prgmd, RFU Filter I/O Codan 90-20593-001 90-20593-001 1
IC3 Array, Transistor
SOIC14
Motorola MC1413D XT-01413-700 1
IC4 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC5 Amp, Oper Dual CMOS
SOIC8
National Semiconduct LMC662CM XA-00662-700 1
IC6 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
J1 Socket, Coax Mini Low Prof
Fixed
Taiko Denki TMP-J02X-A1 60-19390-002 1
J2 Socket, MCX Straight
PCB
Chin Nan 27-05-TGN 60-19300 1
J3 Terminal Block 2 way PCB Phoenix Mecano AK300/2-5,0-GREY 61-10200-202 1
K1 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K2 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K3 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K4 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K5 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K6 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K7 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
K8 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
L2 Ind, 1mH 10% 1812 Coilcraft 1812LS-105XKBC 43-83100-000 1
L3 Ind, 3u36 vi/gn/bk/ye Fetronics 44-70504 44-70504 1
L4 Ind, 2u28 bl/bl/bl/bk Fetronics 44-70476 44-70476 1
L5 Ind, 2u89 vi/gn/bk/or Fetronics 44-70503 44-70503 1
L6 Ind, 2u28 bl/bl/bl/bk Fetronics 44-70476 44-70476 1
L7 Ind, 1,6uH gn/bk/gn Fetronics 44-70465 44-70465 1
L8 Ind, 1,8uH gn/sl/gn Fetronics 44-70466 44-70466 1
L9 Ind, 1u21 vi/gn/bk/rd Fetronics 44-70502 44-70502 1
L10 Ind, 1,2uH sl/sl/sl Fetronics 44-70369 44-70369 1
L11 Ind, 1,6uH gn/bk/gn Fetronics 44-70465 44-70465 1
L12 Ind, 1,0uH sl/sl/or Fetronics 44-70368 44-70368 1
L13 Ind, 712nH bn/sl/bn Fetronics 44-70467 44-70467 1
L14 Ind, 837nH bl/bl/bl/gn Fetronics 44-70477 44-70477 1
L15 Ind, 620nH vi/vi/wh Fetronics 44-70393 44-70393 1
L16 Ind, 499nH vi/gn/bk/bn Fetronics 44-70501 44-70501 1
L17 Ind, 530nH bl/bl/bl/bn Fetronics 44-70478 44-70478 1
L18 Ind, 422nH bl/bl/bl/or Fetronics 44-70479 44-70479 1
L19 Ind, 291nH vi/gn/bk/bk Fetronics 44-70500 44-70500 1
L20 Ind, 422nH bl/bl/bl/or Fetronics 44-70479 44-70479 1
L21 Ind, 80nH vi/gn/bk/bl Fetronics 44-70506 44-70506 1
L22 Ind, 225nH bn/bl Fetronics 44-70470 44-70470 1
L23 Ind, 225nH bn/bl Fetronics 44-70470 44-70470 1
Page 7 of 11
