Codan NGT 2010 RF User Manual

11 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05416-001 - Filter & Control PCB
BOM Revision
Date Valid On
L24 Ind, 267nH vi/ye/wh/wh Fetronics 44-70499 44-70499 1
L25 Ind, Common Mode 1.5A Taiyo Yuden CM05RA06 43-80000 1
L26 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L27 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L28 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L29 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Not Fitted Codan **-00000-001 99-00000-001 1
P2 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P3 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
P4 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
R1 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R2 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R3 33k Ohm 5% 0,125W 1206 Philips 2322 711 61333 40-43300-101 1
R4 100 Ohm 5% 0,33W CF
Res
Philips 2322 211 13101 40-21000-020 1
R5 100 Ohm 5% 0,33W CF
Res
Philips 2322 211 13101 40-21000-020 1
R6 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R7 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R8 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R9 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R10 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R11 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R12 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R13 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R14 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R15 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R16 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R17 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R18 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R19 10k Ohm 2% 0,125W SIL
R/2R 8Bit
Bourns 4610X-R2R-103 40-84109-002 1
R20 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R21 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
