07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05988-001 - Audio & Interconnect PCB
BOM Revision
Date Valid On
IC15 Flip Flop, D Dual
SOIC14
Motorola MC74HC74AD YH-74074-700 1
IC16 Gate, NOR 2 Input Quad
SOIC14
Motorola MC74HC02AD YH-74002-700 1
K1 Relay, 2C 9V Ltch SMD 2x579
Ohm
Matsushita TQ2SL-L2-9V 64-21225-258 1
L1 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
L2 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L3 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L5 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L6 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L7 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L8 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L9 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L10 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L11 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L12 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L13 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L14 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L15 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L16 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L17 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L18 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L19 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Header (P) 12way 2mm Latch
Fixed
AMP 1-173981-2 60-00120-002 1
P2 Header (P) 16way 2row Boxed
SMD 2,54mm
Neltron 2316SMD-16G 60-00160-003 1
P3 Header (P) 26way 2row Boxed
SMD
Neltron 2316SMD-26G-CAP-TR 60-00260-002 1
P4 Header (P) 16way 2row Boxed
SMD 2,54mm
Neltron 2316SMD-16G 60-00160-003 1
P5 Not Fitted Codan **-00000-001 99-00000-001 1
P6 Header (P) 8way 2mm Latch
Fixed
AMP 292161-8 60-00080-001 1
R1 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R2 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R3 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R4 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R5 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R6 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
Page 5 of 9
