Codan NGT 2010 RF User Manual

07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05988-001 - Audio & Interconnect PCB
BOM Revision
Date Valid On
R7 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R8 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R9 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R10 47k Ohm 1% 0,1W 0805 Philips 2322 734 64703 40-44700-115 1
R11 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R12 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R13 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R14 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R15 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R16 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R17 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R18 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R19 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R20 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R21 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R22 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R23 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R24 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R25 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R26 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R27 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R28 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R29 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R30 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R31 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R32 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R33 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R34 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R35 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R36 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
Page 6 of 9
