06 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05987-001 - Appn Proc PCB,3V (Handset I/F)
BOM Revision
Date Valid On
C55 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C56 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C57 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C58 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C59 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C60 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C61 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C62 Not Fitted Codan **-00000-001 99-00000-001 1
C63 Not Fitted Codan **-00000-001 99-00000-001 1
C64 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C65 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C66 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
D1 Diode, Schottky 40V 1A
SMA
Taiwan Semiconductor SS14 MBRA140T3 1
D2 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D3 Diode, Schottky SOT23 Philips BAT54 BAT54 1
H1 Not Fitted Codan **-00000-001 99-00000-001 1
H2 Not Fitted Codan **-00000-001 99-00000-001 1
H3 Not Fitted Codan **-00000-001 99-00000-001 1
H4 Not Fitted Codan **-00000-001 99-00000-001 1
IC1 EPLD prgmd, 2011 RFU DSP Braemac 90-20619-001 90-20619-001 1
IC2 DUART, 16 Byte FIFO 3-5V
4Mbps TQFP48
Exar ST16C2550CQ48 YK-16550-900 1
IC3 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC4 Reg, Voltage +1,8V 150mA
LDO SOT23-5
Texas Instruments TPS76318DBVT XB-76318-700 1
IC5 Reg, Voltage +3,3V 0,5A
Switch SOIC8
National Semiconduct LM2674M-3.3TR XB-02674-701 1
IC6 Micro prgmd, 2011 Master I/O Codan 90-20624-001 90-20624-001 1
IC7 Codec, 16 Bit 22kSPS 3-5V
TQFP48
Texas Instruments TLV320AIC10C YN-32010-900 1
IC8 Amp, Oper Dual CMOS
SOIC8
National Semiconduct LMC662CM XA-00662-700 1
IC9 Serial Number, 48 bit
SOT223
Dallas DS2401Z YM-02401-700 1
IC10 Supervisory, Dual 2,93 & 1,68V
SOIC8
Texas Instruments TPS3305-18DR XD-03305-700 1
IC11 DSP, 32 Bit Fltng Point
60MIPS LQFP144
Texas Instruments TMS320VC33PGE120 YP-32033-900 1
IC12 FLASH prgmd, RF Unit, D0-
D15
Braemac 90-20617-101 90-20617-101 1
IC13 FLASH prgmd, RF Unit, D16-
D31
Braemac 90-20617-201 90-20617-201 1
Page 3 of 7
