Codan NGT 2010 RF User Manual

06 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05987-001 - Appn Proc PCB,3V (Handset I/F)
BOM Revision
Date Valid On
IC14 RAM, CMOS 512kx16Bit 55ns
3V TSOP2-44
Samsung K6X8016T3B-UF55T YM-16512-710 1
IC15 RAM, CMOS 512kx16Bit 55ns
3V TSOP2-44
Samsung K6X8016T3B-UF55T YM-16512-710 1
IC16 Flash 1Mx8bit/512k x16bit 3V
70ns TSOP48
AMD AM29LV800BB70EC YM-29800-701 1
IC17 Supervisory, Pwr&reset 4,63V
SOT23
Maxim MAX810LEUR-T XD-00810-700 1
IC18 Comparator, Rail-Rail I/O LP
SOT23-5
National Semiconduct LMC7221AIM5 XD-07221-700 1
L1 Ind, 680uH Switched Supply Coilcraft DS5022P-684 43-82680-000 1
L2 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L3 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Not Fitted Codan **-00000-001 99-00000-001 1
P2 Not Fitted Codan **-00000-001 99-00000-001 1
P3 Not Fitted Codan **-00000-001 99-00000-001 1
P4 Header (P) 26way 2row Boxed
SMD
Neltron 2316SMD-26G-CAP-TR 60-00260-002 1
P5 Not Fitted Codan **-00000-001 99-00000-001 1
P6 Not Fitted Codan **-00000-001 99-00000-001 1
P7 Not Fitted Codan **-00000-001 99-00000-001 1
P8 Socket, 16way 1row ZIF 1mm
Pitch SMD
Global Shine GS008-16-G-1 60-00163-004 1
R1 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R2 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R3 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R4 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R5 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R6 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R7 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R8 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R9 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R10 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R15 2,2k Ohm 5% 0,06W 0603 Philips 2322 702 60222 40-32200-121 1
R16 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R17 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R18 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R19 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R20 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
Page 4 of 7
