Codan NGT 2010 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06261-001 - Audio Interconnect & Data I/O PCB
BOM Revision
Date Valid On
IC13 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC14 Mux/Demux, Analog, Triple 2ch
SOIC16
Philips HEF4053BT-653 YH-40053-701 1
IC15 Flip Flop, D Dual
SOIC14
Motorola MC74HC74AD YH-74074-700 1
IC16 Gate, NOR 2 Input Quad
SOIC14
Motorola MC74HC02AD YH-74002-700 1
IC17 Gate, AND 2 Input Quad
SOIC14
STMicroelectronics 74LCX08M YX-74008-700 1
IC18 Buffer, Single Non-Inv T/State
SOT323-5
STMicroelectronics 74V1T125CTR YY-74125-700 1
IC19 Amp, Operational Dual
SOIC8
Texas Instruments TL082CD XA-00082-700 1
IC20 Amp, Operational Dual
SOIC8
Texas Instruments TL082CD XA-00082-700 1
IC21 Reg, Voltage +Adj 0,8A
TO252
National Semiconduct LM1117IDTX-ADJ XB-01117-700 1
IC22 Tcvr, IrDA 115k2 bps Side-look
SMD
Zilog ZHX1810MV115THTR YI-01810-700 1
K1 Relay, 2C 9V Ltch SMD 2x579
Ohm
Matsushita TQ2SL-L2-9V 64-21225-258 1
K2 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
L1 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
L2 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L3 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L5 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L6 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L7 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L8 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L9 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L10 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L11 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L12 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L13 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L14 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L15 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L16 Ind, 100uH 10% 4532 Taiyo Yuden LEM 4532T101K 43-82100-134 1
L17 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L18 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L19 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L20 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L21 Choke, EMI/EMC 0A DC
>10MHz 0805
Taiyo Yuden BK 2125 HS 330-T 43-90004 1
P1 Header (P) 12way 2mm Latch
Fixed
AMP 1-173981-2 60-00120-002 1
Page 6 of 12
