Codan NGT 2010 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06261-001 - Audio Interconnect & Data I/O PCB
BOM Revision
Date Valid On
P2 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P3 Header (P) 26way 2row Boxed
Fix
Thomas & Betts 609-2627 60-00260-000 1
P4 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P5 Not Fitted Codan **-00000-001 99-00000-001 1
P6 Header (P) 8way 2mm Latch
Fixed
AMP 292161-8 60-00080-001 1
P7 Header (P) 15way 2mm Latch
Fixed
Chyao Shunn JS-1125-15 60-00150-005 1
P8 Header (P) 10way 2row Boxed
SMD 2,54mm
Neltron 2316SM-10G 60-00100-004 1
P9 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
P10 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
R1 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R2 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R3 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R4 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R5 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R6 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R7 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R8 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R9 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R10 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R11 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R12 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R13 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R14 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R15 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R16 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R17 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R18 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R19 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R20 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R21 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R22 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
